Double Head CNC Router for Slatwall Panel Making

It's A Real High-Speed Double Head CNC Router Slatwall Machine

Guess what the maximum cutting rate of this cnc machine is? If using dual head together to cut MDF panel with good router bits, it’s 20,000mm/min. Yes, 20 meters per minute!

To prove this, we experimented in our workshop before machine delivery; that is, let the Slatwall router to cut the Slat board with different rates and see what the maximum one is.

Background Information Concerning the Experiment:

Materials Sheet: Plywood 25mm thickness

Working Mode: Two head cutting together

Bits: Slatwall Router Bits

Machine: The exact double head cnc router here

Enjoy the video!

As you can see in the video, the first cut is well done with a 15m/min feeding rate, and we increased the feeding rate to 20m/min in the second cut. The cut is very nice as well.

Based on the fact that this is a stepper motor driven machine, we did not continue to increase the feed rate. Just because that, in theory, a feeding rate over 20m/min will harm machine performance and lifespan.

So, as it turns out, the maximum feeding rate is 20m/min when cutting Slatwall MDF panels. It’s also the upper limit of working speed for this Slatwall machine. Of course, in actual production, you can set an appropriate cutting rate according to your own output.

Next, let’s take a look at what speed our customer is using in their plant.

Real Customer Case of Dual Head Slatwall Router EA-2030VMH2

For your information, the customer is using a 10,000mm/min rate in their own production. The first half of the video is the actual production scene taken by the customer himself in his workshop; The second half of the video is how the customer says to us. Enjoy!

To check how the customer says about us, please click here.

The Embodiment of High Configuration on This Double Head CNC Router

• To improve productivity, the machine adopts the design of dual independent heads, and each head is equipped with an Italian HSD6KW spindle motor (AC220V). So, it can cut 2 grooves at a time. That is twice the output of a single head cnc router.

• Another advantage of this design is that one of the machine heads can be moved aside, and then you can use it as a single-head wood router. Therefore, it can be switched between the single-head and double-head working modes at will.

• To maximize the machine's durability, it adopts Taiwan's original linear guide rails and bearings. The brand is PMI, and its life span can be as long as 8 to 10 years.

• To effectively prolong the lifespan of linear guides, the router machine is equipped with a central lubrication system; lubricant can be delivered to each slider through this system.

• The CNC controller is model Lambda3S with MPG (manual pulse generator) from WEIHONG. It is based on the Windows system. Accordingly, the control cabinet is a floor type one that can get the whole computer set (host, monitor, keyboard, and mouse) accommodated there. FYI, the yellow unit in the following photo is the controller hardware.

Q: Are WEIHONG Controllers Windows Based?

A: Yes, they are Windows system based CNC controllers. Therefore, we need to use a desktop computer with a Windows operating system to control and run the cnc router machine. Please see that the laptop doesn't work with Weihong controllers because it does not have a card slot for installing the Weihong control card.

• The operating software of the machine is NcStudio Lambda3S. Please refer to the following picture.

Utilization of Two Head CNC Router

Industry

This double head cnc router is ideal for being applied to Slatwall panel, slat board making, and mass wood carving fields.

Materials good for the dual head cnc router

Good for all kinds of wood, including Solid Wood and MDF, PVC, Formica, Epoxy Tooling board, aluminum, and more.

Quick Details of EagleTec CNC Slatwall Machine

• Bed Size 2000x3000mm

• Dual independent head design, each head with one Italian HSD spindle

• Original HSD air cooling spindle motor 6.0KW – 2PCS

• Heavy-duty machine base

• WEIHONG Lambda3S CNC controller with NcStudio software

• Stepper Motors – 6 PCS

• YAKO YKA2811MA drivers – 6PCS

• Original Taiwan PMI square type linear guides and bearing

• Individual control cabinet

• Central lubrication system

Packing Details About This Double Head CNC Router Slatwall Machine

This machine's effective working size is 3000x2000mm, and the machine dimension has reached 3750x2650mm; Probably, you know that the width of the container is 2300mm. So, to get the machine set accommodated in the container, the gantry should be knocked down to reduce the machine size, as the following picture shows.

Technical Parameter of Slat Board Making Double Head CNC Router Machine

FAQs about Double Head Slatwall Router Machine EA-2030VMH2

Q: Are Assembly Works Required Once It Arrived Here?

A: Yes, it is. As we talked in the previous part of the packing details above, the gantry is taken down to get the machine accommodated in the container. So, once it reaches your plant, you’ll need to assembly the gantry back. Detailed guide tutorials for this job will be provided to you; furthermore, we will guide you online by live chat if you have any questions.

Q: Does This Slatwall Machine Include A Dust Extracting System?

A: Yes, it can be equipped with a dust extracting system if you need it. Please tell us if you need that.

Q: What Kind of Warranty Do You Offer for This Two Head Slatwall Router?

A: It’s a 12-months warranty since the shipping date. Under warranty, you enjoy free replacement for any broken parts except Vulnerable parts. When the warranty expires, we still provide continuous technical support to you.

If you like the double head cnc router here, please inquire now to get a free quotation.
