Model: EA-TL1230SF
Category: CNC Woodworking Lathe
Brand: EagleTec
Condition: New Condition
Reference Price: USD8580.00 / SET
Price Range: USD8580 to USD9998 / SET according to different configuration
Production Capacity: 100 Sets Monthly
Availability: production started after order confirmation (Preorder)
Lead Time: 10 to 15 days
Payment Method: T/T, Western Union, Money Gram
H.S. Code: 84659200.00
Popularity:
4.9 based on 5.0
The woodturning equipment for sale here is a fully automatic wood lathe machine with configuration of auto feed system, one cutter head and one broaching (engraving) head. Autofeed is the biggest advantage of this lathe, with this mechanism, manual loading and unloading is not required any more. Instead of that, it is completely done by itself in auto mode, which increases productivity greatly and saves labor resource for you. In fact, this is the whole point of a truely automatic wood turning machine.
People who are interested in this model also checked out: double axes cnc wood lathe
You will understand clearly how the auto feed system works from this video. The demo here shows the complete machining process, from wood turn blank feed to the finished job. I hope you enjoy it!
A: It depends. To answer this question, we have to consider the product length, the wood blank dimension (depending on how many times of stepdown are required), and raw material property (depending on feed speed). Let’s illustrate with an example here; assuming the product is 600mm long, the material is beechwood, and one time stepdown is enough to complete the turning, such being the case, we can run the turning at a speed of 1,200mm/min. It is calculated that the pure turning process takes 30 seconds. Except for turning, auto loading and motor starts actions will take approximately 30 seconds. So we can see that it takes 1 minute to complete 1 piece from beginning to end. And one hour gets 60 pieces. The speed here refers to the one that gets a good quality finish.
• Whole lathe base is cast in one piece from iron, and this structure is obviously superior to the welded one in rigidity and reliability. All foundation planes are finished through a CNC Mill, not hand-made jobs, to get good accuracy.
• Self-feeder with an air-actuated clamping system improves the wood-turning output greatly. Additionally, this automatic hopper feed mechanism reduces labor resources, in turn, which reduces labor costs for you. Below are pictures of it.
• The controller is a hand-held controller (HHC), which is dedicated to fully automatic wood turning lathes from RichAuto. The model is F1XHAND-H06. It has two language options, English and Chinese. We will set its language to English before delivery. The picture below is a photo of it.
Q: Is the External Computer Needed with The System?
A: We run the lathe with the individual handheld controller; thus, the machine's operation doesn't require an external computer. However, it would help if you had a computer to draw designs in AutoCAD software in your office.
• As you can see in the above photo, the EagleTec wood lathe comes with English labels for operation buttons and switches. EagleTec is a professional in exporting CNC lathes.
• Combination of one knife head and one spindle head makes the auto cnc wood lathe can do wood-turning, twist grooving, and wood-carving jobs. The electric spindle is 3.5kw (4.7hp) air-cooled. Please refer to the pictures below.
• A steady rest comes with the lathe to fix the thin billets as stable as possible; its diameter is 66mm as default, and other sizes can be built as actual needs.
• Rotary axis is driven by a 4.0kw (5.36hp) AC servo motor instead of a 3-phase asynchronous motor. The servo mechanism has many advantages; please click here to check it out. It is the top one thing you should know before buying a cnc lathe for wood.
• The X and Y linear motion axes are driven by a combined mechanism of stepper motor (NEMA34) and YAKO YKA2811MA driver. Model. YKA2811MA is the best stepper driver in China; very durable. You will have no issue at all!
• Independent electronic cabinet design for the automatic wood lathe. Please refer to the following photo.
• The wood turning blank is clamped by an air-actuated tailstock, which is very firm and does not fall off. The diameter of the spike is 20mm. Referring to the photos below.
• Truly automatic workpiece feeding. (hopper feed)
• Working size 11.81"D x 47"L (300 x 1,200mm)
• One blade head + one electronic spindle head combination
• AC servo 5.36HP (4.0KW) as headstock drive
• NEMA34 stepping motor + YAKO YAK2811MA combination as the X and Y drive
• RichAuto hand-held numerical controller special for auto wood lathe, which can read ***.dxf file without making G-code toolpath for turning and broaching jobs. The communication interface is USB.
EagleTec automatic wood lathe machine is delivered and ready to run. Once it arrives, you need to connect each part to run the machine. The process is like buying a new computer, and you need to connect the monitor with the host and the keyboard with the host. The same goes for our machine. Under our specific tutorials in English, it is very simple.
Two sets of wood lathe tools will be provided for free along with this fully automatic wood lathe machine; they are best carbide cutters for woodturning (capable of turning 700 pieces of beechwood before sharpening) and arch type router bit for broaching/fluting.
In addition to the two types of cutters, the free accessories also includes the following items.
Toolbox – 1 Piece
USB flash with specific tutorials from hardware to software in English – 1 Piece
Limit sensor – 1 Piece
ON/OFF button – 1 Piece
Emergency switch – 1 Piece
Spanner – 1 Piece
Our team will guide you in everything from programming to lathe operation after you purchase from us. For your information, the software for the program we are using is AutoCAD. It is simple, just construct several curves and straight lines with the specific measurements you need and then export it with the extension name ***.dxf. If you are interested in learning how to program it in advance, you can check that out here:
In addition to the tutorials, our technical support team is ready to guide you with everything you need to know to start your wood lathe. You can rest assured that you will get constant support or service from us.
Of course, yes. Actually, no matter whether you are using AutoCAD or other software options, just be aware that any software that can export DXF format will work well with the lathe.
EagleTec CNC automatic wood lathe machine is widely applied to joinery to produce in volume turned posts, finials, fence capitals, post capitals, gable finials, turned corbel, table legs, newel posts, handrails, wooden banister, ladder rungs, stair parts, and more other turned products. The turning finish is smooth and clean; the following photos are the turned projects without polishing/sanding yet.
It is capable of turning square and round (dowel) wood such as beechwood, cedar, pearwood, pinewood, American ash, Maple, and natural wood. For your information, the hopper feed unit also works with dowel (round) pieces.
Wood turning, milling, carving, twist grooving, and carving relief on regular round wood.
The package is safe and robust enough for a long-time sea shipment. The proper shipping way for such lathe machines is by Sea. All the EagleTec CNC lathe machine is packed in this way:
• First, tightly wrapped by PVC films for waterproofing.
• Second, the lathe is fixed on the steel pallet by several plywood stakes to ensure the lathe will not move inside the case.
• Third, the whole set is packed into a strong plywood case.
• Fully automatic design with hopper feed device, output increased, and labor cost decreased.
• Capable of wood-turning, broaching, and relief-carving jobs.
• Adopting RichAuto controller dedicated for auto feed cnc wood lathe machines, which can read DXF files directly, no need to make toolpath (G Code).
• EA-TL1230SF is a 2 axis CNC controlled construction as it has one chisel head only.
• Lathe body is fully cast by iron, so the construction is strong enough for high-speed wood-turning production.
• Advanced servo motor mechanism connecting to rotary with timing belt replaces the old structure of 3-phase asynchronous motor connection to rotary via the clutch mechanism. The positioning accuracy of the lathe is much better and more stable, and the misalignment problem does not happen anymore. You can check the complete details out here: the first thing you should know before buy a cnc wood lathe
If you need to perform turning and then twist/fluting, please go with a wood lathe equipped with a milling spindle, like the EA-TL1230SF here; if you only need to do turning in your production, then you can buy a lathe without a milling spindle to avoid wasting money on useless configurations. EagleTec CNC will build your lathe exactly to your needs.
This mainly covers four major steps.
Step 1. According to the shape and size of the wooden spindle you want to make, we first create a drawing that matches the shape and size of the desired product in AutoCAD and save it as a file in ***.dxf format.
Step 2. We save the completed DXF file on a USB flash drive, then insert it into the USB port of the wood lathe controller.
Step 3. Do the setup work before auto processing, which primely includes setting XY=0, turning speed, cut depth of each pass, etc.
Step 4. Run the file, and the lathe will start working automatically.
Daily maintenance mainly includes the following three points:
Point 1. Clean the sawdust falling on the machine transmission parts every day to ensure the accuracy of the transmission components and extend their life.
Point 2. Check the wear of turning and fluting tools regularly and replace them in time.
Point 3. Do lubrication for the lathes regularly.
| Model No. | EA-TL1230SF |
| Lathe Type | Fully automatic lathe machine that turns wood |
| Knife Quantity | One knife |
| Woodturning Blank Diameter | Range from 20 to 300mm (from 0.79" to 11.81") |
| Woodturning Blank Length | Range from 100 to 1200mm (from 3.94" to 47.24") |
| Acceptable Diameter for Hopper Unit | 30 to 100mm (from 1.18" to 3.93") |
| Acceptable Length for Hopper Unit | 200 to 1200mm (from 7.87" to 47.24") |
| Rotary Axis Quantity | One rotary axis - turns one wood piece at a time |
| Broaching (Engraving) Head | 4.7HP (3.5kw) air-cooled, variable rate from 0 to 18,000RPM |
| Max. Simultaneous Axis Quantity | Three |
| Drive Motor for Head Stock | AC Servo 4.0Kw (5.36HP) / AC380V / 8.2A / 25.5N.m / 6000RPM, ＜70dB(A) |
| CNC Controller | RichAuto F1X HAND-H06 with USB interface |
| Machining Capacity | Wood-turning, broaching, relief-carving on round |
| X Y Axes Motor | NEMA34 stepper |
| XY Driver | YAKO YKA2811MA |
| Communication Code | ***.dxf |
| Inverter | 1 Piece |
| Tail Stock | Air actuated tailstock |
| Spike Diameter | 20mm (the smallest part only) |
| Sheath Diameter | 66mm (other sizes can be built as requested) |
| Air Pressure Requirement | 0.6 ~ 0.8 Mpa |
| Working Power | AC380V/50Hz, 3Ph 4 Wire (AC220V/60Hz, 3Ph or Single Phase) |
| Power Consumption | 10KW |
| Current | 16A |
| Circuit Protection | Short-circuit protection, Overload protection |
| Net Weight | 1450KGS |
| Gross Weight | 1520KGS |
| Lathe Foot Print | 118"L x 79"W x 63"H (3000 x 2000 x 1600mm) |
| Package | Fumigation-free wood case |
| Packing Dimension | 3150 x 1710 x 1480mm (7.97 CBM around) |
A: The shortest piece in length you can process is 100mm.
A: Yes, it does.
A: Yes, it has two language options: English and Chinese. We will set its language to English before delivery.
A: Yes, it does. A complete set of manuals, including text and video will be provided to you on a USB drive. Below is a demo for your reference.
A: The lathe can run files of two formats: DXF and G-code. The output code of Vcarve is G-code. So, it can work with Vcarve also.
A: The air compressor is required for the lathe's operation but not included in the default configuration. There are air compressors in most of the workshops. Except for this, there are no other optional items.
A: As both the auto-feed system and air-actuated tailstock need compressed air to move, the automated wood lathe here can't run without the air compressor.
A: Our team will guide you directly to diagnose the issue by means of live chat, email, PDF, or video instructions. So kindly contact us when your lathe has an issue; usually, you will get a solution within 24 hours. Since we have been focusing on wood lathes for more than 10 years, everyone on our team is an expert at troubleshooting. You will risk nothing if you work with us.
A: All wood turning machines for sale from EagleTec are covered with a 12-month warranty since departure. During the warranty, you will enjoy free replacement for any broken parts, excluding the Vulnerable parts. You can check more here: EagleTec Warranty Terms
A: We are always here for you to offer the replacement parts along with the best support. Whenever you need it, just contact us.
A: The grooving tool on the CNC wood lathe can move left, right, forward, and backward along the workpiece's centerline, as it only has two axes of motion. Consequently, it can handle mortises located on the centerline, but there are limitations on the shape and size of the mortises it can handle. The machine has very limited capabilities in the mortise.
A: It is safe and robust enough for a long-time sea shipment. The proper shipping way for such a lathe machine is by Sea. The automatic wood turning lathe machine is packed in this way:
First, tightly wrapped in PVC films for waterproofing.
Second, the lathe is fixed on the steel pallet by several plywood stakes to ensure the lathe will not move inside the case.
Third, the whole set is packed into a strong plywood case.
A: A 40% deposit is required to start the production; when the lathe is ready, photos and videos will be sent to you for inspection. And then, the balance payment should be made by T/T before delivery.
If you like this automatic wood lathe machine here, please contact us now.
